XT100

Power. Performance. Price Advantage.

Eliminating the pitfalls and hidden costs associated with deploying consumer-grade devices in the enterprise, Janam’s XT100 rugged touch computer delivers the best of both business and personal. It packs the power and performance of a rugged mobile computer in a slim smartphone design to meet the diverse needs of mobile workers across every industry.  With more features and functionality than any other device in its class, the XT100 delivers the latest technological advances to organizations of all sizes at an extremely attractive price point.

Featuring a brilliant 4.3-inch touch screen with Corning® Gorilla® Glass 3, wide-viewing angle and daylight readability, the XT100 provides maximum performance indoors and outdoors. In addition, the XT100 can withstand repeated drops, accidental spills, extreme temperatures and exposure to elements to eliminate downtime and increase productivity. Optional Qi compatible wireless charging capabilities increase efficiency and safety in industrial applications.

The XT100 addresses the most demanding data capture requirements with integrated 2D barcode scanning technology, 13MP/2MP rear- and front-facing cameras and NFC and RFID reading capabilities to ensure users can capture business-critical information with unparalleled speed and accuracy. 4G LTE connectivity provides lightning-fast voice and data, empowering mobile workers with real-time access to the information they require to get their jobs done.

A familiar form factor and support for the widely deployed Android 6 operating system help reduce training time and drive immediate productivity gains. Certification by Google Mobile Services ensures XT100 users have access to all Google APIs, including those for Google PlayTM, Google MapsTM and ChromeTM.

Specifications

TECHNICAL



Operating System

Android 6

Processor

1.2 GHz Qualcomm Snapdragon™ 410 quad-core

Memory

2GB/16GB

Expansion

User-accessible microSD card slot with SD and SDHC support

Power

3000mAh rechargeable Li-ion battery

PHYSICAL



Dimensions

2.76” x 5.35” x 0.69” / 70mm x 136mm x 17.4mm

Weight

7.5oz / 213g including battery

Display

4.3” WVGA (480 x 800 pixel) with Corning Gorilla Glass 3

Touch Panel

Capacitive touch screen

ENVIRONMENTAL



Operating Temperature

-4º to 140º F / -20º to 60º C

Storage Temperature

-13º to 158º F / -25º to 70º C

Humidity

Non-condensing, 95%

Drop

Multiple 4ft / 1.2m drops to concrete across a wide temperature range

Water & Dust

IP65

Electro Static Discharge (ESD)

+/- 15kV air; +/- 8kV contact

INTERFACE FEATURES



Audio

3.5mm headset jack; speaker; 2 microphones

Alerts

Vibration; LED indicators

Connectors

MicroUSB supports USB 2.0 High-Speed

LED Indicators

Dual-color LED indicators

External Buttons

3 hard keys

DATA CAPTURE



Imager

Honeywell N6603 2D Imager

RFID/NFC Reads ISO14443 Type A; ISO14443 Type B & ISO15693; MIFARE UltraLight; MIFARE UltraLight C; MIFARE 1k/4k/Plus; MIFARE DESFire;MIFARE DESFire EV1; NFC in the 13.56MHz range


WIRELESS COMMUNICATION



WWAN

EDGE/GPRS/GSM: 900/1800
WCDMA: B1/2/5/6/8/19
LTE FDD: B1/2/3/5/7/8/17/20
LTE TDD: B40/41

WLAN

Dual-band 802.11a/b/g/n/d/h/i/k/r/v

Security

IEEE802.11; WEP; WPA/WPA2; PEAP/MSCHAPv2; EAP-TLS

WPAN

Bluetooth v4.1

MOBILE APPURTENANCES



Motion Sensor

Gyroscope; Accelerometer; Light sensor; Proximity sensor; Digital compass

GPS

Qualcomm® GPS supports GLONASS

Camera

13MP color rear-facing autofocus camera with user-controllable LED flash and 2MP front-facing camera

ACCESSORIES

Single-slot cradle kit (Ethernet; Charging)



Four-slot charging cradle kit



Power adapter

Spare battery
Four-slot battery charging kit

SAFETY/REGULATORY



Safety

IEC 60950; EMC; RF; SAR; LED; Laser

Radio

FCC; IC; GCF; CE

Environment

RoHS and WEEE compliant

                                           Specifications Subject to Change.
