HT1

Built to Excel in Demanding Environments.

With an increasing demand for more screen viewability, rugged tablet adoption in the enterprise continues to rise. Janam’s HT1 exceeds enterprise expectations – delivering a powerful and advanced 8-inch rugged tablet for retail, warehousing, manufacturing, field service, fleet-based operations and other demanding work environments.

Slim and light, the HT1 is ergonomically designed for one-handed use and is as stylish as a consumer tablet. The powerful HT1 offers speed and performance to help organizations achieve maximum productivity. A blazing-fast Snapdragon octa-core processor boosts efficiency, while an 8200mAh swappable and rechargeable battery provides all-day battery life for uninterrupted usage in extended-shift work environments.

Wi-Fi, Bluetooth, NFC and 4G LTE connectivity allow factory and warehouse workers, field service technicians, police officers, nurses and airline personnel, among others, to access business-critical information anywhere their job takes them.

The HT1 is IP67-rated and MIL-STD-810G military grade certified to ensure protection against dust, water, vibrations, drops, extreme temperatures and varying altitudes.


Specifications

TECHNICAL



Operating System

Android 9 (Pie) with Google Mobile Services (GMS);

Processor

2.0 GHz Qualcomm Snapdragon™ 625 octa-core

Memory

4GB LPDDR3 RAM/64GM eMMC Flash

Expansion User-accessible microSD card slot with SDXC support; SIM slot

Power

8200mAh 3.8V swappable, rechargeable Li-ion battery

PHYSICAL



Dimensions

9.25” L x 5.74” W x .57” D /
235mm L x 146mm W x 14.5mm D

Weight

22.7oz / 645g including battery

Display

8.0” HD with Corning® Gorilla® Glass 3; 400+ nits

Touch Panel

Capacitive touch screen

ENVIRONMENTAL



Operating Temperature

-4º to 131º F / -20º to 55º C

Storage Temperature

-40º to 158º F / -40º to 70º C

Humidity

Non-condensing, 95%

Drop

Multiple 4ft / 1.2m drops to concrete
per MIL-STD-810G and MIL-STD-810F

Water & Dust

IP67

Electro Static Discharge (ESD)

+/- 15kV air; +/- 8kV contact

INTERFACE FEATURES



Audio

3.5mm headset jack; 2 speakers; 2 noise-cancelling microphones; Push-to-Talk support

Alerts

Vibration; LED indicators

Connectors

USB-C; Pogo Pin industrial connector

LED Indicators

Dual-color

Motion Sensor Accelerometer; Light Sensor; Proximity
Sensor; Digital Compass
External Buttons 8 hard keys

DATA CAPTURE



Imager

High-performance 1D/2D imager (optional)
Camera 13MP color rear-facing autofocus camera with user-controllable LED flash and 5MP front-facing camera
RFID/NFC Reads ISO14443 Type A; ISO14443 Type B; IEC15693

WIRELESS
COMMUNICATION



WWAN

GSM: 850/900/1800/1900
TD-SCDMA: B34/39
WCDMA: B1/2/5/8
CDMA/EVDO: BC0
LTE FDD: B1/2/3/4/5/7/8/12/13/17/20/25/28
LTE TDD: B38/B39/B40/41

WLAN

802.11a/b/g/n/ac

Security IEEE 802.11n; WEP; WPA/WPA2 Personal
(TKIP. AES); WPA/WPA2 Enterprise (TKIP, AES);
PEAP(MSCHAPv2, GTC): TLS; TTLS
(PAP, MSCHAP, MSCHAPv2, GTC); PWD; SIM;
AKA; AKA’, LEAP
 WPAN Bluetooth Class I 4.1 (BLE)
GPS GPS supports GLONASS

ACCESSORIES

Desktop Charging Cradle

Vehicle Cradle
Handstrap

SAFETY/REGULATORY



Safety

IEC60529:2013; IEC68-2-32:1990;
GB4208-2008; GB/T2423.8-1995

Radio

FCC; CE; IC; RCM; MIL-STD-461F

Environment

RoHS; REACH and WEEE compliant

                                           Specifications Subject to Change.

Accessories

Cradle Kits

  • Single-Slot USB/Ethernet Cradle Kit for HT1

    Single-Slot USB/Ethernet Cradle Kit for HT1

    ( CKT-H1-001UE)
    Includes power supply.

Batteries & Chargers

  • Standard Battery for HT1

    Standard Battery for HT1

    ( BAT-H1-001)
    8200mAh 3.8V

Expanded Performance

  • 2D Imager Attachment for HT1 Series

    2D Imager Attachment for HT1 Series

    (ATC-HT!-1)
  • Handstrap for HT1

    Handstrap for HT1

    (HS-T-004)
Resources

Product files and documents


HT1 User Manual PDF file, 3 MB
HT1 Datasheet PDF file, 399.97 KB
